Socket AM5

Memory Support DDR5 6600+(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200(OC)/ 5000(OC)/ 4800(JEDEC) MHz

Max. overclocking frequency:

• 1DPC 1R Max. speed up to 6600+ MHz

• 1DPC 2R Max. speed up to 6000+ MHz

• 2DPC 1R Max. speed up to 6400+ MHz

• 2DPC 2R Max. speed up to 4000+ MHz

Support Dual-Channel mode

Supports non-ECC, un-buffered memory

Supports AMD EXPO™

1x DisplayPort

Support HDMI™ 2.1 HDR, maximum resolution of 4K 60Hz

Support DP 1.4 HBR3, maximum resolution of 8K 60Hz

1x PCI-E x1 slot

PCI_E1 PCIe 4.0 supports up to x16 (From CPU)

PCI_E2 PCIe 4.0 supports up to x2 (From Chipset)

PCI_E3 PCIe 3.0 supports up to x1 (From Chipset)

M.2_1 (From CPU) supports up to PCIe 5.0 x4 , supports 2280/2260 devices

M.2_2 (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260 devices

M.2_3 (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260 devices

6x SATA 6G port

4x USB 2.0 (Front)

4x USB 3.2 Gen1 Type A (Rear)

2x USB 3.2 Gen1 Type A (Front)

3x USB 3.2 Gen2 Type A (Rear)

1x USB 3.2 Gen2 Type C (Front)

1x USB 3.2 Gen2x2 Type C (Rear)

The Wireless module is pre-installed in the M.2 (Key-E) slot

Supports MU-MIMO TX/RX

Supports 20MHz, 40MHz, 80MHz,160MHz bandwidth in 2.4GHz/ 5GHz or 6GHz bands

Supports 802.11 a/ b/ g/ n/ ac/ ax

Supports Bluetooth® 5.2

7.1-Channel USB High Performance Audio

Supports up to 32-Bit/384 kHz playback on front panel

2x Power Connector(CPU_PWR)

1x CPU Fan

1x Pump Fan

6x System Fan

2x Front Panel (JFP)

1x Chassis Intrusion (JCI)

1x Front Audio (JAUD)

1x Tuning Controller connector(JDASH)

2x Addressable V2 RGB LED connector (JARGB_V2)

2x RGB LED connector(JRGB)

1x TPM pin header(Support TPM 2.0)

4x USB 2.0

2x USB 3.2 Gen1 Type A

1x USB 3.2 Gen2 Type C

1x EZ LED Control switch

2.5G LAN

USB 2.0 (Type-A)

Wi-Fi / Bluetooth

Audio Connectors

Flash BIOS Button

HDMI™

USB 3.2 Gen 2 10Gbps (Type-A)

USB 3.2 Gen 2×2 20Gbps (Type-C)

USB 3.2 Gen 1 5Gbps (Type-A)

Optical S/PDIF Out

243.84mmx304.8mm
