General Features |
Application |
Client PCs |
Rated Capacity |
1,000 GB (1 GB=1 Billion byte by IDEMA) * Actual usable capacity may be less (due to formatting, partitioning, operating system, applications or otherwise) |
Form Factor |
2.5 inch |
Interface |
SATA 6 Gb/s Interface, compatible with SATA 3 Gb/s & SATA 1.5 Gb/s interface |
Dimension (WxHxD) |
100 X 69.85 X 6.8 (mm) |
Weight |
Approx. 46.0g Weight |
Storage Memory |
Samsung V-NAND 4bit MLC |
Controller |
Samsung MKX Controller |
Cache Memory |
Samsung 1 GB Low Power DDR4 SDRAM |
Special Feature |
TRIM Support |
TRIM Supported |
S.M.A.R.T Support |
S.M.A.R.T Supported |
GC (Garbage Collection) |
Auto Garbage Collection Algorithm |
Encryption Support |
AES 256-bit Encryption (Class 0),TCG/Opal, IEEE1667 (Encrypted drive) |
WWN Support |
World Wide Name supported |
Device Sleep Mode Support |
Yes |
Performance |
Sequential Read |
Up to 560 MB/s Sequential Read * Performance may vary based on system hardware & configuration |
Sequential Write |
Up to 530 MB/s Sequential Write * Performance may vary based on system hardware & configuration ** Measured with Intelligent TurboWrite technology being activated |
Random Read (4KB, QD32) |
Up to 98,000 IOPS Random Read * Performance may vary based on system hardware & configuration ** Measured with Intelligent TurboWrite technology being activated |
Random Write (4KB, QD32) |
Up to 88,000 IOPS Random Write * Performance may vary based on system hardware & configuration ** Measured with Intelligent TurboWrite technology being activated |
Random Read (4KB, QD1) |
Up to 11,000 IOPS Random Read * Performance may vary based on system hardware & configuration ** Measured with Intelligent TurboWrite technology being activated |
Random Write (4KB, QD1) |
Up to 35,000 IOPS Random Write * Performance may vary based on system hardware & configuration ** Measured with Intelligent TurboWrite technology being activated |
Environment |
Average Power Consumption (system level) |
Average: 2.2 W *Maximum: 4.0 W (Burst mode)* Actual power consumption may vary depending on system hardware & configuration |
Power consumption (Idle) |
Max. 30 mW * Actual power consumption may vary depending on system hardware & configuration |
Allowable Voltage |
5V ± 5% Allowable voltage |
Reliability (MTBF) |
1.5 Million Hours Reliability (MTBF) |
Operating Temperature |
0 – 70 ℃ Operating Temperature |
Shock |
1,500 G & 0.5 ms (Half sine) |
Accessories |
Installation Kit |
Not Available |
Software |
Management SW
Magician Software for SSD management |
Endurance |
360 TBW |
Warranty |
3 Years |
Note |
*** Features, Price, Specifications are subject to change without notice. |
