Fractal Design Meshify 3 Black TG Light Tint ATX Mid Tower Cabinet

The tempered glass Meshify 3 in black. Fractal's 2025 refresh, with a new Momentum fan platform and an angled power supply shroud whose air guide channels intake straight onto the graphics card. Noise normalised CPU temperatures improved from 48 to 40 degrees over ambient versus the previous generation in GamersNexus testing.

Read this before you buy

The Meshify 3 is a smaller case than the Meshify 2. Graphics card clearance is 349mm rather than 470mm, and power supply length 180mm rather than 250mm. Check your parts before upgrading across generations.

Cooling

Three 140mm Momentum 14 fans at the front. Liquid crystal polymer blades, true fluid dynamic bearings, Fractal Connect single connector daisy chaining. Radiators to 360mm front, 280mm top, 120mm rear.

Clearances

• Graphics card: up to 349mm length, 176mm thickness
• CPU cooler: up to 173mm
• Power supply: ATX up to 180mm

Specifications

• Model: Meshify 3 Black TG Light Tint. Part number FD-C-MES3A-02
• Type: ATX mid tower, 46.79 litres
• Motherboard support: E-ATX up to 277mm, ATX, Micro ATX, Mini ITX
• Dimensions: 433 x 229 x 507mm
• Material: Steel chassis and mesh front, light tint tempered glass left panel, steel right panel
• Included fans: 3 x 140mm Momentum 14, non lit, 4 pin PWM, front intake
• Radiator support: Front 120, 240, 280 or 360mm. Top 120, 140, 240 or 280mm. Rear 120mm
• Fan mounts: Front 3 x 120/140mm. Top 2 x 120/140mm. Rear 1 x 120mm
• Drive bays: 2 dedicated 2.5 inch, 4 combined 3.5 or 2.5 inch
• Expansion slots: 7
• Front IO: 2 x USB Type-A 5Gbps, 1 x USB Type-C 20Gbps, audio and microphone combo jack, power button
• Dust filters: PSU filter only, slides out sideways from the case leg
• Warranty: 2 years

In the box: Cabinet with 3 pre installed Momentum 14 fans, drive trays, accessory box, manual.
